HF
Precision laser cutting machine
Application Area
- ·锯片制造
- ·硅矽钢片
- ·电子元件
- ·精密器械
- ·工艺礼品
- ·眼镜制造
Product details
Marble base, accurate positioning;
Beam lightweight design, strong acceleration performance;
Linear motor platform drive, high precision, good stability, long service life;
High precision transmission and control system, high equipment performance
Full closed-loop integrated control, FAGOR grating ruler, Japan THK grinding guide rail, drive control integrated controller and other components, to build a complete set of high-precision transmission and control system to ensure the efficient and stable performance of the equipment
Technical Parameter
| Laser cutting machine | HF6060 | HF8080 | HF100100 | HF125125 | |
| Cut sheet size（mm） | 600*600 | 800*800 | 1000*1000 | 12500*12500 | |
| Machine stroke(mm) | X axis | 600 | 800 | 1000 | 1250 |
| Y axis | 600 | 800 | 1000 | 1250 | |
| Z axis | 100 | 100 | 100 | 100 | |
| Maximum linkage positioning speed(m/min) | 200 | 200 | 200 | 200 | |
| Maximum acceleration | 2G | 2G | 2G | 2G | |
| Positioning accuracy(mm/m) | ±0.02 | ±0.02 | ±0.02 | ±0.02 | |
| Repeated positioning accuracy(mm) | 0.01 | 0.01 | 0.01 | 0.01 | |
| Equipment area (length * width * height)（mm） | 1430*1800*1800 | 1805*2200*1900 | 2100*2400*1900 | 2370*2630*2080 | |
*The appearance, parameters, performance description, and comparative data of the products displayed on this page are for reference only, and the actual product shall prevail.
Application Industry
-
锯片制造
-
硅矽钢片
-
电子元件
-
精密器械
-
工艺礼品
-
眼镜制造
Product Video
