HLW
2 Chuck laser pipe cutting machine
Application Area
- ·Fitness equipment
- ·Office furniture
- ·Automobile manufacturing
- ·Bridge tunnel
- ·Construction machinery
- ·Metalwork
High dynamic performance
Chuck moving speed 120m/min, speed 120r/min, acceleration 1.2G, excellent dynamic performance greatly improve the production efficiency.
Machining accuracy and working intensity are guaranteed
Equipped with three servo servo support, to provide the best guarantee for high-precision cutting needs of users;
With semi-automatic feeding device, it can reduce the working intensity of workers and improve the feeding efficiency
Front chuck avoidance front
Cutting head in front of chuck
Front chuck avoid back
The cutting head is behind the chuck
Minimum tail material ≤40mm
Improve the cutting precision of the end material
Facilitate the processing of short raw materials proofing or mass production
A variety of blanking methods are available
The optional flip plate cutting device can make the cutting of long workpiece more stable and higher precision. Manual lifting, can also be upgraded to follow the lifting, the cutting accuracy of long material is more guaranteed.
Groove cutting device can be selected to meet the diversified needs of customers
Intelligent bus operating system
Rich laser pipe cutting machine special functions
Meet a variety of processing needs
Equipped with professional customized pipe nesting software
Achieve efficient management of production schedule and quotation accounting
Technical Parameter
| Laser cutting machine | HLW-6528 | HLW-9528 | HLW-6536 | HLW-9536 |
| Working stroke（mm） | Round tube：φ15-φ280 | Round tube：φ15-φ280 | Round tube：φ20-φ360 | Round tube：φ20-φ360 |
| Square tube：□15-□250 | Square tube：□15-□250 | Square tube：□20-□250 | Square tube：□20-□250 | |
| Feeding length（mm） | ≤6500 | ≤9600 | ≤6600 | ≤9600 |
| Maximum linkage positioning speed(m/min) | 120 | 120 | 120 | 120 |
| Maximum acceleration | 1.2G | 1.2G | 1.2G | 1.2G |
| Positioning accuracy(mm/m) | ±0.03 | ±0.03 | ±0.03 | ±0.03 |
| Repeated positioning accuracy(mm) | 0.02 | 0.02 | 0.02 | 0.02 |
| Residual length（mm） | ≤40 | ≤40 | ≤40 | ≤40 |
| Laser power | 3000W～12000W | |||
*The appearance, parameters, performance description, and comparative data of the products displayed on this page are for reference only, and the actual product shall prevail.
