ROL
Coil laser cutting machine
Application Area
- ·Furniture kitchen and bath
- ·Chassis cabinet
- ·Metal doors and Windows
- ·Elevator manufacturing
- ·Shelf truss
- ·Hvac equipment
Continuous cutting, release efficiency
Coil equipment 24 hours continuous transmission;
Feed and discharge simultaneously;
Production efficiency doubled;
Heavy material rack, force top thousand catties
Cantilever structure, stress annealing, frame high load bearing;
Stable operation, frequency conversion control, stable discharge;
Hydraulic expansion, flexible operation;
Remove stress and cut smoothly
After the coil is unrolled, flatten the sheet with a leveling machine;
Eliminate the stress of the plate, make the plate more flat;
Ensures smoother cutting
High speed cutting
Laser cutting machine high-speed cutting, improve the utilization rate of the plate
Technical Parameter
| Laser cutting machine | ROL1530 | ROL1540 | ROL2060 | |
| Machine stroke(mm) | X axis | 1550 | 1550 | 2050 |
| Y axis | 3050 | 4050 | 6050 | |
| Z axis | 100 | 100 | 100 | |
| Maximum linkage positioning speed(m/min) | 180 | 180 | 180 | |
| Maximum acceleration | 1.5G | 1.5G | 1.5G | |
| Positioning accuracy(mm/m) | ±0.03 | ±0.03 | ±0.03 | |
| Repeated positioning accuracy(mm) | 0.02 | 0.02 | 0.02 | |
| Feed rate（m/min） | ≤30 | ≤30 | ≤30 | |
| Feeding accuracy（mm/m） | ±0.50 | ±0.50 | ±0.50 | |
| Laser power can be matched | 3000W～12000W | |||
*The appearance, parameters, performance description, and comparative data of the products displayed on this page are for reference only, and the actual product shall prevail.
Application Industry
-
Furniture kitchen and bath
-
Chassis cabinet
-
Metal doors and Windows
-
Elevator manufacturing
-
Shelf truss
-
Hvac equipment
